Project Description
IP54 Water-proof LED bathroom lamp light 15w CE certification
Item No.:QK-TRIP05(OVAL)& TRIP06(ROUND)
Power available:8w,12w,15w,18w or customized power output
two profiles for option: oval and round
Features:
- IP54 Water-proof,dust-proof and mosquito-proof
- High quality LED CHIPS 2835: high CRI more than 80, high lumen up to 80 lumens/wattage
- No flicker LED DRIVER
- No UV and IR radiation
- Easy installation by the screw on the wall or ceiling
- 3 Years Guarantee
- CE Compliant
Parameters:
Power | 8w | 12w | 15w | 18w |
---|---|---|---|---|
ITEM No. | QK-TRIP05 | QK-TRIP05 | QK-TRIP05 | QK-TRIP05 |
Lumens | ≥640 | ≥960 | ≥1200 | ≥1440 |
Led Driver | IC Driver No flicker | IC Driver No flicker | IC Driver No flicker | IC Driver No flicker |
Led Chips | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 |
Input Voltage | AC85-264V | AC85-264V | AC85-264V | AC85-264V |
Dimension | 168*70*46 mm | 168*70*46mm | 208*100*52mm | 208*100*52mm |
IP rating | IP54 | IP54 | IP54 | IP54 |
CRI | ≥80 | ≥80 | ≥80 | ≥80 |
Body Material | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) |
Power | 8w | 12w | 15w | 18w |
---|---|---|---|---|
ITEM No. | QK-TRIP06 | QK-TRIP06 | QK-TRIP06 | QK-TRIP06 |
Lumens | ≥640 | ≥960 | ≥1200 | ≥1440 |
Led Driver | IC Driver No flicker | IC Driver No flicker | IC Driver No flicker | IC Driver No flicker |
Led Chips | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 |
Input Voltage | AC85-264V | AC85-264V | AC85-264V | AC85-264V |
Dimension | 140*140*57 mm | 140*140*57mm | 170*170*57mm | 170*170*57mm |
IP rating | IP54 | IP54 | IP54 | IP54 |
CRI | ≥80 | ≥80 | ≥80 | ≥80 |
Body Material | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) | PS(BODY)+ABS(BASE) |
Product Details:
Installation:
Can be installed on the wall or ceiling by the screw directly.
Applications:
bathroom/corridor/ toilet/storage /balcony/ garage
Package & Delivery:
- 1 PC in the white or color box and 40 pcs in the outer carton, or Customized package acceptable
- A normal order shall be delivered in 2 weeks after the payment or contract or negotiable delivery time
- OEM or ODM order delivery time depends on the contract
Payment:
Paypal, T/T, L/C or other feasible payment modes according to the agreement or contract.
